Model No. |
VCF-009T |
|
HDMI Input Interface |
1x HDMI |
|
HDMI Loop Out Interface |
1x HDMI |
|
HDCP Decryption |
2.2/1.4 |
|
HDMI Color Precision |
4:2:2 |
|
HDMI Color Space |
YUV |
|
HDMI Video Input Formats |
UltraHD: 3840 x 2160p_60, 59.94, 50, 30, 29.97, 25, 24
HD: 1920 x 1080p_60, 59.94, 50, 30, 29.97, 25, 24
HD: 1920 x 1080i_60, 59.94, 50
HD: 1280 x 720p_60, 59.94, 50, 30, 29.97, 25 |
|
SDI Output Interface Type |
1x BNC-F |
|
SDI Signal |
12G-SDI, 6G-SDI, 3G-SDI, HD-SDI |
|
SDI Video Output Digital |
12Gb-SDI: 3840 x 2160p_60, 59.94, 50
6Gb-SDI: 3840 x2160p_30, 29.97, 25, 24
3Gb-SDI (Level A): 1080p_60, 59.94, 50
1.5Gb-SDI: 1080p_30, 29.97, 25, 24
1080i_60, 59.94, 50
720p_60, 59.94, 50, 30, 29.97, 25 |
Max. Output Coax Length |
12G-SDI: 80 Meters
6G-SDI: 80 Meters
3G-SDI: 120 Meters
HD-SDI: 120 Meters |
|
SDI Color Precision |
4:2:2 |
|
SDI Color Space |
YUV |
|
Audio Format |
PCM2.0, 16-24bit(48KHz) |
|
Power Supply |
DC12V, 1.0A |
|
Operating Temperature |
-10°C ~ 40°C |
|
Storage Temperature |
-20°C ~ 60°C |
|
Operating Relative Humidity |
10-90% noncondensing |
|
Dimensions |
95 x 80 x 20mm |
|
Weight |
200g |
|
Warranty |
1-year warranty |
Product specifications are subject to change without notice. |
