Model No. |
VCF-005HR |
|
Connections |
|
|
SDI Video Inputs |
1 x HD-SDI/3G-SDI with embedded audio |
|
SDI Video Outputs |
1 x HD-SDI/3G-SDI loopout with embedded audio |
|
SDI Rates |
HD-SDI/3G-SDI |
|
SDI Compliance |
SMPTE425M(Level A and Level B)
SMPTE424M
SMPTE292M
SMPTE259M-C and DVB-ASI |
|
SDI Transmitting distance |
Belden 1694A : 120m at 2.97Gb/s
200m at 1.485Gb/s |
|
AHD/TVI/CVI Video Outputs |
1 x BNC |
|
AHD/TVI/CVI Transmitting distance |
300 meters |
|
HDMI Video Outputs |
1 x TypeA (v1.4a) |
|
Standards |
|
|
SDI Video Input Standards |
720p60_59.94_50Hz
1080i 60_59.94_50Hz
1080p 60_59.94_50_30_25Hz |
|
SDI Color Precision |
4:2:2 |
|
SDI Color Space |
YUV |
|
AHD/TVI/CVI Video Output Standards |
720p 30_25Hz
1080p 30_25Hz
NTSC, PAL |
|
HDMI Video Output Standards |
720p 60_50Hz
1080p 60_50Hz |
|
VGA Video Output Standards |
720p 60_50Hz
1080p 60_50Hz |
|
General |
|
|
Power Supply |
DC12V, 1A |
|
Operating Temperature |
-10°C ~ 55°C |
|
Storage Temperature |
-30°C ~ 60°C |
|
Relative Humidity |
10 ~ 90% RH (Non-condensation) |
|
Dimensions |
153mm x 90 x 25mm |
|
Weight |
328g |
|
Casing |
Iron Case |
|
Warranty |
1-year warranty |
