Model No. |
ACT-VF03 |
|
Connections |
|
|
AHD / TVI / CVI Video Inputs |
1 x BNC -F |
|
AHD / TVI / CVI Video Outputs |
1 x loop out (BNC - F) |
|
Input Signal Type |
AHD / CVI / TVI / CVBS All Type |
|
SDI Outputs |
1 x SDI (without embedded audio) |
|
SDI Rates |
HD-SDI / 3G-SDI |
|
SDI Compliance |
SMPTE425M(Level A and Level B)
SMPTE424M
SMPTE292M
SMPTE259M-C and DVB-ASI |
|
SDI Transmitting distance |
Belden 1694A : 120m at 2.97Gb/s
200m at 1.485Gb/s |
|
HDMI Video Outputs |
1 x TypeA (v1.4a) |
|
Standards |
|
|
AHD/TVI/CVI Video Standards |
3840 x 2160 (4K) 15_12.5Hz
2592 x 1944 (5MP) 15_12.5Hz
2560 x 1440 (4MP) 30_25Hz
1920 x 1080p 30_25Hz
1280 x 720p 30_25Hz |
|
SDI Video Standards |
1920 x 1080p 60_50Hz
1920 x 1080i 60_50Hz
1280 x 720p 60_50Hz |
|
SDI Color Precision |
4:2:2 |
|
SDI Color Space |
YUV |
|
HDMI Video Standards |
1920 x 1080p 60_50Hz
1280 x 720p 60_50Hz |
|
VGA Video Standards |
1920 x 1080p 60_50Hz
1280 x 720p 60_50Hz |
|
General |
|
|
Power Supply |
DC12V, 1A |
|
Power Consumption |
3.6 Watts |
|
Operating Temperature |
-10°C ~ 55°C |
|
Storage Temperature |
-30°C ~ 60°C |
|
Relative Humidity |
20 ~ 90% RH (Non-condensation) |
|
Dimensions |
153mm x 90 x 25mm |
|
Weight |
328g |
|
Casing |
Iron Case |
|
Warranty |
1-year warranty |
