UVB-4K UVC to HDMI Adapter
Description Features
• USB Camera to HDMI Signal Converter
• Input resolution up to 3840×2160p (4K_30fps), backward compatible.
• HDMI video output with matching resolution.
• Supports Universal Video Class (UVC), plug-and-play with most systems.
• Supports mouse access for adjusting camera parameters conveniently.
• Power consumption is under 2W for energy efficiency.
pic
pic
pic
pic

 Model No. UVB-4K
 USB Input USB x 2 (USB2.0)
 Video Input UVC Camera
 Input Resolution 3840×2160p backwards compatible
1080p 60_50_30_25Hz
1080i 60_50_30_25Hz
720p 60_50_30_25Hz
 Video Output HDMI x 1 (HDMI 2.0)
 HDMI Output Resolution 3840×2160p 30Hz
1080p 60_50_30_25Hz
1080i 60_50_30_25Hz
720p 60_50_30_25Hz
Same as input resolution
 Mouse Access Supports adjusting camera parameters
 Product Support List Logitech USB Camera, GoPro13, DJI pocket3/action4/action5, Insta X3/X4/X5
 Power Supply DC 5V / 2A (Type-C)
 Power Consumption < 2W
 Operating Temperature -20°C to +60°C
 Operating Humidity < 90%, no condensation
 Dimensions 680mm × 430mm × 220mm
 Weight 50g

 Product specifications are subject to change without notice.




Package does not include a 5V power supply.
CategoriesFile NameDownload
title shadow
awUser ManualUVB-4K User's Manual (E)Download
awProduct CatalogUVB-4K (E)Download
